PGS25e Electric Pressure Pump

Pressure generation made easy: generate pressure and vacuum, quickly and precisely with out manual efforts in a range between -0.900 and 25 bar



Description

The EIUK PGS25e is a portable bench top electric pressure pump for industrial pressure calibration applications in ranges from -12.3 psi (-0.900 bar) up to 363 psi (25 bar).

It provides an effortless and quick way to generate pressure, with-out the need of a pressure source connected. It simply uses ambient air to generate and control pressure.

The PGS25e is ideal for all industrial pressure calibration applications which  include calibration of pressure instruments such as pressure transmitters, digital and analogue pressure gauges, pressure switches, pressure sensors and virtually any other pressure instruments.

The PGS25e is extremely easy to use: simply select pressure or vacuum generation, turn on the pump and set the desired pressure test point by using the fine control, effortless with-out any manual effort.

This electric pump is equipped with 2 pressure ports, one for the unit under test and the second one for the reference instruments. It is compatible with all the pressure calibrators available in the market so you don’t need to  purchase a new one.



Specifications

Specifications
Pressure Range  0 to 25 bar/363 psi
Vacuum Range*  0 to -0.900 bar/-13.7 psi
Pressure Adjustment Better than 1 mbar
Pressure Ports 2 x fitted pressure ports with dirty separator  G1/2″ and G1/4″
Medium Air
Vetted Parts Stainless steel, nickel-plated brass, brass, FKM
General
Power Supply 110…230 VAC (incl. power supply unit to 24 VDC / 1.5 ADC)
Motor Specifications  24 VDC, 220 Ncm, 0.88 A
Temperatures Operation 0…50°C (+32…+122°F); Storage -20…+60°C (-4…+140°F)
Dimension Approx. 271 x 228 x 116 mm (without power supply unit)
Weight Approx. 2.9 kg (without power supply unit)
Housing ABS
Notes * At nominal barometric pressure of 1013 mbar abs
